Noraplate is a high-gloss black paint film, decorative and developed for automotive components (trims) made on stainless steel or aluminium. They offer a premium visual quality and withstand thermoforming operations
These films offer strong resistance to ultraviolet exposure, maintaining colour depth and surface brilliance over time.
The outer layer resists mechanical wear, light scratching and typical automotive fluids.
It is the perfect combination between aesthetic performance, durability and industrial robustness for automotive applications.
| DESCRIPTION | STANDARD | TEST | UNIT | RESULT | OBSERVATIONS |
|---|---|---|---|---|---|
| Total coating thickness | EN 13523-1 | ASTM D1005 | mils | 1.65 – 1.73 | Film + adhesive |
| Specular Gloss (Gardner 60º) * | EN 13523-2 | ASTM D523 | % | 90(±5) | Glossy |
| Visual comparison | EN 13523-3 | ASTM E1347 | — | Pass | |
| Pencil hardness | EN 13523-4 | ASTM D3363 | scale | F | |
| Cross-cut test | EN ISO 2409 | ASTM D3359 | scale | 0-1 | Pass |
| Cupping test -normal -with scribe | EN-13523-6 | ASTM E643 | mm | Pass Pass | Cupping 8 mm |
| T Bend test | EN 13523-7 | ASTM D522 | — | 0,5-1T | No whitening, no cracking |
| Resistance to salt spray | EN 13523-8 | ASTM B117 | hours | > 500 | Pass |
| Taber abrasion (CS 10, 500 g) -After humidity | UNE 48250 | ASTM 4060 | cycles | 750 | No metal affected slight coating affect |
| Resistance to accelerated Xenotest ageing test | EN 13523-10 | ASTM D6695 | hours | > 5000 | No visual changes, no change on gloss |
| Humidity test | EN 6270-2 | ASTM D2247 | hours | 240 | Pass |
| Heat cycle-80ºC/ 15 days | N/A | — | days | Pass | No visual change |
| Chemical resistance after 24 hours(sulfuric acid, sodium hydroxide and sodium chloride) | N/A (intenal) | 0.1N H2SO4 0.1N NaOH 3% NaCl | hours | Pass | No discoloration |
| Commercial cleaning agents (inmersion) – Car Shampoo (24 h) – Windows cleaner (1 h) – Polish wax (10 min)• | hours | Pass | No changes on surface |
